170tons best price ISO9001T-slot electric switch socket high speed energy saving PP PE plastics
injection molding machine
1. Any inquires will be replied in the first time.
2. High quality products, competitive price, fast lead time.
3. Our sales staff will be have a good communication with you ,let
you fully understand the situation of our enterprises and products.
4. We will provide high quality overseas service ,our technical
staff will be able to provide you with technical support ,for you
personally to overseas assembly and test equipment.
5. Our customer service staff will put your feedback to the
technical staff in the first time, timely solve your problem.
Description:
Injection moulding machine: Adopting Europe technology,hydraulic
unit adopts proportional pressure and flow control,the pressure and
the speed can be adjusted,stable movement curve and gentle
shock,the computer is imported from Industry family.
Main technical parameters
| Product Name | 170 Injection molding machine price |
| Capacity | 10-15 cartoon/min |
| Table height | 800mm |
| Applicable size | (L)300-400×(W)300-450×(H)100-200 |
| Machine size | (L)4.85m×(W)1.3m×(H)2.1m |
| Machine weight | 4600KG |
| Rated power | 4KW |
| Power supply | 220V 60HZ |
| Air supply | 150L/min 6Mpa |
| Hot melt adhesive | curing time 2-3 seconds,working temperature: 150-180°C |
Characteristics
1. Adopts the imported control components, durable, safe, and low
failure rate.
2. Use human-computer interface, simple and more visually oriented.
3. The machine uses machine electrical and air linkage, excellent
effect of bottom sealing.
4. East to adjust different sizes of cartons, adjust quickly and
easily, available for a wide range of cartons.
5. Low power consumption, simple and convenient operation, low
noise.
6. Use tap to seal the cartoon bottom, protected from weather,
sealing reliable.
Shipping and Payment
| Product Name | 170 Injection molding machine price |
| Packing | Export standard package |
| MOQ | 1 set |
| FOB price | Please contact for new price |
| Delivery time | 25days |
| FOB port | Ningbo |
| Payment terms | T/T,L/C at sight |
Specification
| SL170 | | A | B | C |
| INJECTION UNIT |
| SCREW DIAMETER | mm | 42 | 46 | 50 |
| SCREW L/D RATIO | L/D | 21.9 | 20.0 | 18.4 |
| SHOT SIZE(THEORETICAL) | cm³ | 290 | 348 | 412 |
| INJECTION WEIGHT(PS) | g | 264 | 317 | 375 |
| INJECTION PRESSURE | Mpa | 215 | 180 | 152 |
| CLAMPING UNIT |
| CLAMPING FORCE | Kn | 1700 |
| TOGGLE STROKE | mm | 440 |
| SPACE BETWEEN TIE BARS | mm | 470*470 |
| MAX.MOULD HEIGHT | mm | 520 |
| MIN.MOULD HEIGHT | mm | 170 |
| EJECTOR STROKE | mm | 145 |
| EJECTOR TONNAGE | Kn | 49 |
| MAX.TEMPLATE SPACE | mm | 960 | | |
| DIE HOLE DIAMETER | mm | 125 | | |
| EJECTOR NUMBER | PC | 5 |
| OTHERS |
| MAX.PUMP PRESSURE | Mpa | 16 |
| TEMPERATURE CONTROL | paragraph | 3+1 |
| MACHINE DIMENSION(L*W*H) | m | 4.85*1.3*2.1 |
| MACHINE WEIGHT | Ton | 4.6 |
| OIL TANK CUBAGE | L | 230 |
