    Air Cooled Industrial Air Chiller Machine 8AC Industrial Cooling Systems Chillers

    Ask Lasest Price
    Brand Name : TAIHONG
    Model Number : KCM-8AC
    Certification : CE
    Price : 1
    Payment Terms : Western Union, MoneyGram, T/T
    Supply Ability : 300
    Delivery Time : 7days
    • Product Details
    • Company Profile

    Air Cooled Industrial Air Chiller Machine 8AC Industrial Cooling Systems Chillers


    • compressor is used ”COPELAND” brand which made in the USA. The inside safety protection can guarantee the long lasting of chiller well. The pump is used made in Taiwan and all parts of cooling system are imported from the USA. Mexico. Denmark and Japan .
    • Equipped with shell pipe condenser and stainless steel cased evaporator, which are quite easy to be cleaned and maintained. equipped with automatic water supply device in the water-tank. Air cooled cased chiller with board type evaporator is suitable for the district of water resource and district of poor water quality.
    • larger than model XC-20 are assembles 2 sets 4 sets of compressors. So they are able to used as separate or together to reduce the resource waste complete with safety protection and error indication.
    • system including compressor over load, protection, pump over load protection, high pressure and low pressure protection and phase failure protection.

    Equipment with figure intellectualized temperature control. Which can accurately measure and control

    Water temperature within the range of 5℃-35℃.
    Air Cooled Cased Industrial Chiller(KCM-AC)

    model
    Parameter


    Specification

    KCM-3ACKCM-5ACKCM-8ACKCM-10ACKCM-12ACKCM-15ACKCM-20ACKCM-25ACKCM-30ACKCM-40ACKCM-50ACKCM-100AC
    Cooling capacityKcal/h680012040190002520034400370004500054000766009280011300024300
    CompressorAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed VorticityAll-closed Vorticity

    Screw
    compressor

    Compressor powerKw2.54.47910.213.41820.426.8354074
    RefrigerantR22R22R22R22R22R22R22R22R22R22R22R22

    Chilled water
    pump power

    Kw0.750.750.750.750.751.51.51.52.27.57.58

    Max flow rate
    of chilled water

    L/min55120120200200400400400400600600900

    Flow water inlet
    and ourlet pipe

    1''1''1.5''1.5''1.5''1.5''2''2''2''3''3''5''
    Chilled fan powerKw0.250.50.50.50.5111.51.53.23.25
    size lengthmm103011001220122012201220170019801900200021003600
    size widthmm6807008009309301050110011601200120013001800
    size heightmm127014001450160016001600192018002000210021001800

    Water tank
    capa

    L5388120200200240380600550Dry-type evaporator
    WeightKg21029040045050055070075082098016002800

    Maintenance
    1. Keep the loose-heating water tower clean and make around of tower in fresh air and in low temperature. And avoid mess entering into freezing tower for fear affecting efficiency of loose-heating.
    2. With air cooling chiller, pls. keep the surface of loose-heating coil pipe clean, make around r in fresh air and in low temperature. And clean the dirt of coil pipe always in order to make a good efficiency of change-heating.
    3. Arrange technician to clean evaporator when the chiller have been used over six months or high/low pressure appears failure always.
